Double way rupture discs for pressure and vacuum protection
Rupture discs designed to protect industrial systems against both overpressure and vacuum conditions.
The rupture disck that protects both ways: against pressure and vacuum
Instances of application exist where an industrial plant must be simultaneously protected against excessive pressure and against the vacuum, since both may cause damage. To combine protection against pressure and counterpressure specific burst disks are employed, which fall under the heading of “double-way”.
DonadonSDD’s Bi-directional rupture discs can manage both pressure and counterpressure; they have a composite structure, with two separate metal discs (which may be calibrated at different levels) and an internal PTFE membrane. Installation procedure is remarkably simplified, since they can be installed directly between the plant’s flanges.
Contact us today for more information regarding our double way rupture discs!
Frequently Asked Questions
Depending on disc’s type, DonadonSDD can supply discs from 1/8” (3mm) up to 40” (1000mm) in diameter.
You can download here the RUPTURE DISC FORM that will guide You to collect all the data required, which can be also summarized as below specified:
- required burst pressure & burst temperature
- nominal size, flange rating & face finishing
- disc and holder material
- vacuum resistance (if requested)
- Pressure Safety Valve protection (if requested)
There are several other factors as well, so DonadonSDD specialists are always at disposal to specify the correct disc for any application. Each and every rupture disc we design and deliver to our customers is scrupulously custom-built, so as to match the industrial plant’s specific and unique needs.
Main Families: Forward / Reverse / Sanitary
The categories of rupture & bursting disks which we manufacture for our customers, are:
- NS NANOSCORED RUPTURE DISCS – a unique, top-performing product.
- SANITARY RUPTURE DISCS – for pharmaceutical, food and biotech industries.
- FORWARD ACTING – the traditional, time-tested solution.
- REVERSE ACTING – sporting better resistance to different operating pressures.
- ULTRA LOW PRESSURE RUPTURE DISCS – sensitive to even the lightest pressures.
- DOUBLE WAY – protects both ways: against pressure and vacuum.
- GRAPHITE RUPTURE DISCS – for aggressive fluids.
- SEALED UNIT – simple and quick to install.
